The diamond wire saw is widely used in mining of all kinds of granite, as well as in leveling granite mines. It has the characters of high cutting efficiency, low pollution, and high output rate, high cost effective.
Product Description
The diamond wire saw is widely used in mining of all kinds of granite, as well as in leveling granite mines. It has the characters of high cutting efficiency, low pollution, and high output rate, high cost effective.
Technology Parameter of Wire Saw
Identification | Specification（mm） | Beads/meter | Fixed | Cutting material | Line speed（m/s） | Cutting speed（㎡/h） | Life length（㎡/m） |
QLR40 | Φ 9.0 | 40 | Rubber | Low rigidity granite | 24-28 | 6-12 | 10-15 |
Φ 11.0 | Mid-rigidity granite | 22-24 | 4-10 | 6-10 | |||
QLR38 | Φ 11.5 | 38 | Hard granite | 18-22 | 3-6 | 4-8 | |
QLR40 | 40 | Strong abrasive granite | 26-30 | 2-4 | 3-6 |
Technology Parameter of String Bead
Specification（mm） | Outer diameter（mm） | Height of work layer（mm） | Length（mm） | Manufacture tech |
Φ 9.0 | Φ 9.0 | 6.0 | 9.5 |
Sintered
|
Φ 11.0 | Φ 11.0 | 6.4 | 10.0 | |
Φ 11.5 | Φ 11.5 | 10.8 |
Our Advantages
1. Extensive production experience: We are specialized in diamond wire saw with an experience of 26 years.
2. Complete production facilities. Our technicians will do regular scheduled maintenance on these machines to guarantee them work well.
3. Strict Physical/Chemical testing procedures: Meeting the requirements of the product design and process, providing reliable testing data.
Our service
Provide product usage guide;
Professional technical training according to the contract;
Remote technical consulting and services;
Other special technical service according to client’s requirements.
FAQ
1. Q: How does your factory do regarding quality control?
A: Quality is priority. we always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.
2. Q:What's your warranty terms?
A: We offer different warranty time for different products. Please contact with us for detailed warranty terms.
3. Q: When we receive your machine ,is there any other Accessories we will get?
A: Yes,some easy abrasion spare parts will be provided free in case when some small problems happen.
4. Q:What about the transportation?
A: Usually we take seaway,cause it's more convenient and cheaper.
