Product Description
Diamond segment for mine can be suitable for granite, marble, basalt, sandstone and other stone mining and cutting, with the characteristics of fast cutting, large cutting, and long life. The following is the specific parameter information of diamond segments for granite cutting, please follow me to continue reading.
Specification and size of diamond segment and combination method of blade size
2.2m/3.3m, 2.2m/3.6m, 2.4m/3.3m, 2.4m/3.6m
Blank thickness(mm) | Blanks diameter(mm) | Blanks tips(PCS） | Segment size（mm） |
Φ9.5 | Φ2200 | 132 | 23*13/14*15 |
Φ9.5 | Φ2400 | 135 | 23*13/14*15 |
Φ9.5 | Φ3300 | 175 | 23*11.5/12.5*15 |
Φ9.5 | Φ3600 | 180 | 23*11.5/12.5*15 |
Combination method of blades
2.6m/3.6m/4.2m, 2.6m/3.8m/4.5m, 2.6m/3.8m/4.8m.
Blank thickness(mm) | Blanks diameter(mm) | Blanks tips(PCS） | Segment size（mm） |
Φ9.5 | Φ2600 | 140 | 23*15/16*15 |
Φ9.5 | Φ3600 | 180 | 23*14/15*15 |
Φ11 | Φ3800 | 190 | 23*14/15*15 |
Φ11 | Φ4200 | 210 | 23*13/14*15 |
Φ11 | Φ4600 | 225 | 23*13/14*15 |
Φ11 | Φ4800 | 235 | 23*13/14*15 |
Product feature
1.High sharpness: fast cutting speed, low machine current, flat mining.
2. High service life: reduce the number of re-welding of the saw blade substrate, maximize the service life of the substrate, and reduce the cutting cost of mining enterprises.
3. Strong usability: suitable for different stone and various complex and harsh mining environments.
Customer questions
1）. 24-hour Online service
Please feel free to contact us. Our sales team will provide you with 24 hours better pre-sale,
2）. Competitive price
All of our products are supplied directly from factory. So the price is very competitive.
3）. Warranty
All products have a one-two years warranty.
4）. OEM/ODM
With 26 years experiences in this field, we can provide customers with professional suggestion. To promote common development.
FAQ
1. How can I place an order?
You can contact any of our sales person for an order. Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
For designing or further discussion, it is better to contact us with Skype, Trade Manager or QQ or Whatsapp or other instant ways, in case of any delays.
2. When can I get the price?
Usually we quote within 24 hours after we get your inquiry.
3. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, etc. You can choose the one which is the most convenient
or cost effective for you.
We are factory ,we can guarantee our price is first-hand, High quality and competitive price.
